材质：采用不锈钢30偈料
特性：耐酸、耐腐蚀、扩张强度高、滚珠式结构具有 简单、快捷、不可解开等安装上的优势。
使用：室内外都适用，非常方便及快速安装
工作温度：-80℃~500℃
Material: Stainless steel 304
Characteristic: they have an unique ball locking mecha nism that allow easily and quickly installed and not undone For indoor and Outdoor use
Operating temperature: -80℃ - 500℃
编号Item No. | L 长 | W 宽 (mm) | 最大束线径 | 拉力TENSILE STRENGTH(mm) | |||
INCH | MM | INCH | MM | MAX BUNDLE DIA径(mm) | LBS | N | |
HS-4.6x150SST | 5.9 | 150 | 0.18 | 4.6 | 37 | 225 | 1000 |
HS-4.6x200SST | 7.9 | 200 | 0.18 | 4.6 | 50 | ||
HS-4.6x250SST | 9.8 | 250 | 0.18 | 4.6 | 63 | ||
HS-4.6x300SST | 11.8 | 300 | 0.18 | 4.6 | 76 | ||
HS-4.6x350SST | 13.8 | 350 | 0.18 | 4.6 | 89 | ||
HS-4.6x400SST | 15.7 | 400 | 0.18 | 4.6 | 102 | ||
HS-4.6x450SST | 17.7 | 450 | 0.18 | 4.6 | 115 | ||
HS-4.6x500SST | 19.7 | 500 | 0.18 | 4.6 | 128 | ||
HS-7.9x150SST | 5.9 | 150 | 0.31 | 7.8 | 25 | 500 | 2220 |
HS-7.9x200SST | 7.9 | 200 | 0.31 | 7.8 | 37 | ||
HS-7.9x250SST | 9.8 | 250 | 0.31 | 7.8 | 63 | ||
HS-7.9x300SST | 11.8 | 300 | 0.31 | 7.8 | 76 | ||
HS-7.9x350SST | 13.8 | 350 | 0.31 | 7.8 | 89 | ||
HS-7.9x400SST | 15.7 | 400 | 0.31 | 7.8 | 102 | ||
HS-7.9x450SST | 17.7 | 450 | 0.31 | 7.8 | 115 | ||
HS-7.9x500SST | 19.7 | 500 | 0.31 | 7.8 | 128 | ||
HS-7.9x550SST | 21.7 | 550 | 0.31 | 7.8 | 141 | ||
HS-7.9x600SST | 23.6 | 600 | 0.31 | 7.8 | 154 | ||
HS-12x150SST | 5.9 | 150 | 0.47 | 12 | 37 | 700 | 3115 |
HS-12x200SST | 7.9 | 200 | 0.47 | 12 | 50 | ||
HS-12x250SST | 9.8 | 250 | 0.47 | 12 | 63 | ||
HS-12x300SST | 11.8 | 300 | 0.47 | 12 | 76 | ||
HS-12x350SST | 13.8 | 350 | 0.47 | 12 | 89 | ||
HS-12x400SST | 15.7 | 400 | 0.47 | 12 | 102 | ||
HS-12x450SST | 17.7 | 450 | 0.47 | 12 | 115 | ||
HS-12x500SST | 19.7 | 500 | 0.47 | 12 | 128 | ||
HS-12x550SST | 21.7 | 550 | 0.47 | 12 | 141 | ||
HS-12x600SST | 23.6 | 600 | 0.47 | 12 | 154 | ||
HS-16x200SST | 7.9 | 200 | 0.59 | 15 | 37 | 920 | 4100 |
HS-16x250SST | 9.8 | 250 | 0.59 | 15 | 63 | ||
HS-16x300SST | 11.8 | 300 | 0.59 | 15 | 76 | ||
HS-16x350SST | 13.8 | 350 | 0.59 | 15 | 89 | ||
HS-16x400SST | 15.7 | 400 | 0.59 | 15 | 102 | ||
HS-16x450SST | 17.7 | 450 | 0.59 | 15 | 115 | ||
HS-16x500SST | 19.7 | 500 | 0.59 | 15 | 128 | ||
HS-16x550SST | 21.7 | 550 | 0.59 | 15 | 141 | ||
HS-16x600SST | 23.6 | 600 | 0.59 | 15 | 154 | ||
HS-16x650SST | 25.6 | 650 | 0.59 | 15 | 167 | ||
HS-16x700SST | 27.6 | 700 | 0.59 | 15 | 175 | ||
HS-16x800SST | 31.5 | 800 | 0.59 | 15 | 193 | ||
HS-16x1000SST | 39.4 | 1000 | 0.59 | 15 | 206 | ||
